TWFOST-6A 6 Cores Fiber Optic Splice Tray

Fiber optic splice trays are used as an important accessory for fiber cable management items. Such as fiber optic terminal box, fiber optic splice closure, ftth terminal box, cabinet, etc. Splice tray expands fiber splice capabilities. Each tray provides space for mounting fiber splice protectors and excess fiber. The cables are left in the splice tray. The splice tray offers a unique and flexible splice and storage system.
Characteristics
Clear and smart design
Easy to installation
6 cores capacity
Excellence in fiber protection
Durable injection-molded plastic trays and covers
Center holes for mounting of the tray
Applications
Optical distribution frame
Fiber optic terminal box and FTTH terminal box

Read More

60mm Single Fiber Protection Sleeve

Shrinkable sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing.
The sleeve can be divided into two types (single sleeve and ribbon sleeve) according to the function.
The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.
Ribbon sleeve means there are several cores for the fiber. So the mass sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).
Characteristics
Single holed (pre-shrunk)
Clear sleeve design
Smooth stainless steel reinforcing member
Sealing structure suitable to temperature
Extended liner length
Low shrink temperature
Pre installed stainless steel or ceramic rod
Accommodates single or ribbon fibers
Wide range of sizes
Operating temperature -45degree to 100degree
Min. full recovery temp: 120degree
Applications
Fusion splicing,
Fiber cable protecting
Specifications
Size    Splice protector(mm)    Fusion tube(mm)    Steel rod(mm)    Packing
    O.D    L    I.D    L    O.D    L    (pcs/bag)
Large sleeves
TWSP-61    3    61    1.4    61    1.5    55    100
TWSP-45    3    45    1.4    45    1.5    40    100
TWSP-23    3    23    1.4    23    1.5    18    100
Standard sleeves
TWSP-61T    2.5    61    1.4    61    1    57    100
TWSP-45T    2.5    45    1.4    45    1    41    100
TWSP-40T    2.5    40    1.4    40    1    36    100
TWSP-30T    2.5    2.5    1.4    30    1    36    100
TWSP-25T    2.5    2.5    1.4    25    1    21    100
Mini/micro sleeves
TWSP-40M    1.3    40    0.35    40    0.5    40    100
TWSP-25M    1.3    25    0.35    25    0.5    25    100
TWSP-18M    1.3    18    0.35    18    0.5    18    100
TWSP-15M    1.3    15    0.35    15    0.5    15    100
TWSP-10M    1.3    10    0.35    10    0.5    10    100


Properties    Test Method    Typical Data
Tensile Strength（MPa)    ASTM D2671    18
Ultimate Elongation (％)    ASTM D2671    700
Density(g/cm3)    ISO R1183D    0.94
Dielectric Strength(KV/mm)    IEC 243    20
Dielectric Constant    IEC 243    2.5
Longitudinal Change (％)    ASTM D2671    5
Operating Temperature (℃)    -55～+60
Shrinking Temperature Range (℃)    +90～+110
Ordering Information
Illustration

Read More

50mm Single Fiber Protection Sleeve

Shrinkable sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing.
The sleeve can be divided into two types (single sleeve and ribbon sleeve) according to the function.
The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.
Ribbon sleeve means there are several cores for the fiber. So the mass sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).
Characteristics
Single holed (pre-shrunk)
Clear sleeve design
Smooth stainless steel reinforcing member
Sealing structure suitable to temperature
Extended liner length
Low shrink temperature
Pre installed stainless steel or ceramic rod
Accommodates single or ribbon fibers
Wide range of sizes
Operating temperature -45degree to 100degree
Min. full recovery temp: 120degree
Applications
Fusion splicing,
Fiber cable protecting
Specifications
Size    Splice protector(mm)    Fusion tube(mm)    Steel rod(mm)    Packing
    O.D    L    I.D    L    O.D    L    (pcs/bag)
Large sleeves
TWSP-61    3    61    1.4    61    1.5    55    100
TWSP-45    3    45    1.4    45    1.5    40    100
TWSP-23    3    23    1.4    23    1.5    18    100
Standard sleeves
TWSP-61T    2.5    61    1.4    61    1    57    100
TWSP-45T    2.5    45    1.4    45    1    41    100
TWSP-40T    2.5    40    1.4    40    1    36    100
TWSP-30T    2.5    2.5    1.4    30    1    36    100
TWSP-25T    2.5    2.5    1.4    25    1    21    100
Mini/micro sleeves
TWSP-40M    1.3    40    0.35    40    0.5    40    100
TWSP-25M    1.3    25    0.35    25    0.5    25    100
TWSP-18M    1.3    18    0.35    18    0.5    18    100
TWSP-15M    1.3    15    0.35    15    0.5    15    100
TWSP-10M    1.3    10    0.35    10    0.5    10    100


Properties    Test Method    Typical Data
Tensile Strength（MPa)    ASTM D2671    18
Ultimate Elongation (％)    ASTM D2671    700
Density(g/cm3)    ISO R1183D    0.94
Dielectric Strength(KV/mm)    IEC 243    20
Dielectric Constant    IEC 243    2.5
Longitudinal Change (％)    ASTM D2671    5
Operating Temperature (℃)    -55～+60
Shrinking Temperature Range (℃)    +90～+110
Ordering Information
Illustration

Read More

45mm Single Fiber Protection Sleeve

Shrinkable sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing.
The sleeve can be divided into two types (single sleeve and ribbon sleeve) according to the function.
The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.
Ribbon sleeve means there are several cores for the fiber. So the mass sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).
Characteristics
Single holed (pre-shrunk)
Clear sleeve design
Smooth stainless steel reinforcing member
Sealing structure suitable to temperature
Extended liner length
Low shrink temperature
Pre installed stainless steel or ceramic rod
Accommodates single or ribbon fibers
Wide range of sizes
Operating temperature -45degree to 100degree
Min. full recovery temp: 120degree
Applications
Fusion splicing,
Fiber cable protecting
Specifications
Size    Splice protector(mm)    Fusion tube(mm)    Steel rod(mm)    Packing
    O.D    L    I.D    L    O.D    L    (pcs/bag)
Large sleeves
TWSP-61    3    61    1.4    61    1.5    55    100
TWSP-45    3    45    1.4    45    1.5    40    100
TWSP-23    3    23    1.4    23    1.5    18    100
Standard sleeves
TWSP-61T    2.5    61    1.4    61    1    57    100
TWSP-45T    2.5    45    1.4    45    1    41    100
TWSP-40T    2.5    40    1.4    40    1    36    100
TWSP-30T    2.5    2.5    1.4    30    1    36    100
TWSP-25T    2.5    2.5    1.4    25    1    21    100
Mini/micro sleeves
TWSP-40M    1.3    40    0.35    40    0.5    40    100
TWSP-25M    1.3    25    0.35    25    0.5    25    100
TWSP-18M    1.3    18    0.35    18    0.5    18    100
TWSP-15M    1.3    15    0.35    15    0.5    15    100
TWSP-10M    1.3    10    0.35    10    0.5    10    100


Properties    Test Method    Typical Data
Tensile Strength（MPa)    ASTM D2671    18
Ultimate Elongation (％)    ASTM D2671    700
Density(g/cm3)    ISO R1183D    0.94
Dielectric Strength(KV/mm)    IEC 243    20
Dielectric Constant    IEC 243    2.5
Longitudinal Change (％)    ASTM D2671    5
Operating Temperature (℃)    -55～+60
Shrinking Temperature Range (℃)    +90～+110
Ordering Information
Illustration

Read More

40mm Single Fiber Protection Sleeve

Shrinkable sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing.
The sleeve can be divided into two types (single sleeve and ribbon sleeve) according to the function.
The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.
Ribbon sleeve means there are several cores for the fiber. So the mass sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).
Characteristics
Single holed (pre-shrunk)
Clear sleeve design
Smooth stainless steel reinforcing member
Sealing structure suitable to temperature
Extended liner length
Low shrink temperature
Pre installed stainless steel or ceramic rod
Accommodates single or ribbon fibers
Wide range of sizes
Operating temperature -45degree to 100degree
Min. full recovery temp: 120degree
Applications
Fusion splicing,
Fiber cable protecting
Specifications
Size    Splice protector(mm)    Fusion tube(mm)    Steel rod(mm)    Packing
    O.D    L    I.D    L    O.D    L    (pcs/bag)
Large sleeves
TWSP-61    3    61    1.4    61    1.5    55    100
TWSP-45    3    45    1.4    45    1.5    40    100
TWSP-23    3    23    1.4    23    1.5    18    100
Standard sleeves
TWSP-61T    2.5    61    1.4    61    1    57    100
TWSP-45T    2.5    45    1.4    45    1    41    100
TWSP-40T    2.5    40    1.4    40    1    36    100
TWSP-30T    2.5    2.5    1.4    30    1    36    100
TWSP-25T    2.5    2.5    1.4    25    1    21    100
Mini/micro sleeves
TWSP-40M    1.3    40    0.35    40    0.5    40    100
TWSP-25M    1.3    25    0.35    25    0.5    25    100
TWSP-18M    1.3    18    0.35    18    0.5    18    100
TWSP-15M    1.3    15    0.35    15    0.5    15    100
TWSP-10M    1.3    10    0.35    10    0.5    10    100


Properties    Test Method    Typical Data
Tensile Strength（MPa)    ASTM D2671    18
Ultimate Elongation (％)    ASTM D2671    700
Density(g/cm3)    ISO R1183D    0.94
Dielectric Strength(KV/mm)    IEC 243    20
Dielectric Constant    IEC 243    2.5
Longitudinal Change (％)    ASTM D2671    5
Operating Temperature (℃)    -55～+60
Shrinking Temperature Range (℃)    +90～+110
Ordering Information
Illustration

Read More

1*3 Single-mode Monolithic Steel Fused Fiber Optic Splitter

Fiber optic splitter, also called optical splitter, fiber optic coupler, is a device used in optical fiber systems with one or more input fibers and one or several output fibers. There are mainly two types of optical splitters. One is fused splitter (FTB), the other is Planar Light-wave Circuits (PLC Splitter).For the fused optical splitter, It can be divided into different ratios. such as 50/50 if the split is even, or 80/20 if 80% of the signal goes to one side and only 20% to the other Planar Light-wave Circuits (PLC Splitter) cannot work with different ratio rather than it provide a accurate splitting in high-density output (like 8,16,32,64 outputs) However, The most common type of fiber optic splitter splits the output evenly, which is coming out with the same output of light signals. As a result of its great function, Optical splitter is a very important part in passive optic networks (PON).
Characteristics:
Different combinations of coupling ratio
Low crosstalk & excess loss
High optical return loss
Available in dual/three wavelength operation
Optional connector termination upon request
Available in 250um & 900um fiber, 2mm or 3mm
Application:
FTTH, LAN, PON & Optical CATV
Local ring net, Optical fiber communication system
Optical fiber test equipment
Optical fiber sensor
Parameters
Parameter Single-mode Fiber Optic Splitter Type
   Configuration   NX4   N×8 N×16 NX32
Parameter    N=1,2,4             N=1,2,8 N=1,2,16 N=1,2,32
Grade Grade A
Wavelength (nm) 1310nm ,1550nm,1310&1550nm,1310&1490&1550nm
Bandwidth (nm) 13/15±40nm,1490±10nm
Max. Excess Loss 0.3dB 0.45dB 0.6dB 0.78dB
Typical IL 6.3dB 9.5dB 12.8dB 16.2dB
Max.IL 7.8dB 10.4dB 13.8dB 17.2dB
Polarization DL ≤0.2dB ≤0.3dB ≤0.4dB ≤0.5dB
Uniformity(dB) 1.2dB 1.8dB 2.4dB 3dB
Thermal Stability ≤0.2dB /℃ ≤0.3dB /℃ ≤0.4dB /℃ ≤0.5dB /℃
Directivity (dB) ≥60dB
Temperature(℃) -40℃to +85℃
Package Type 1.bare fiber                                                                                                                               2.0.9/2.0/3.0mm loose tube,                                                                                                         3.connector type: FC/APC,FC/PC,SC/APC,SC/PC, all are optional


Pigtail length 1 meter, others on request
Package 100×80×10mm 100×80×10mm 120×92×15mm 140×115×18mm
Order Information
Wavelength Package Size Ports Fiber Types Fiber Cable Connector
13=1310nm FB=bare fiber 102 0=G652D 1=250um 0=0m 1=SC/APC
14=1490nm ST=stainless 103 1=G657A 2=900mm 1=1m 2=SC/PC
15=1550nm Steel tube 104 C=customize 3=2.0mm 2=1.5m 3=FC/APC
35=1310nm PB=plastic 105 　 4=3.0mm 3=2.0m 4=FC/PC
&1550nm MB=Metal ……. 　 　 C=customize 5=ST/APC
345=1310&1490 　 196 　 　 　 6=ST/PC
&1550nm 　 203 　 　 　 7=LC/APC
　 　 204 　 　 　 8=LC/PC
　 　 205 　 　 　 9=Customize
　 　 …… 　 　 　 　
　 　 296 　 　 　 　
　 　 202 　 　 　 　
　 　 404 　 　 　 　
　 　 808 　 　 　 　
　 　 1616 　 　 　 　

Read More
